Production Introduction
PCBA For Outdoor Power Supplies is a multifunctional portable AC/DC emergency power supply device. It features a safe lithium-ion battery and advanced inverter conversion technology, serving as a lightweight, high-capacity, and high-power backup power station. It provides a reliable power solution for mobile offices, medical rescue, fire emergency response, power equipment repair, environmental and territorial protection, emergency communication support, and vehicle storage backup.
Technical Features of PCBA for Outdoor Power Supplies
Compact and lightweight design for easy portability.
AC output options: 220V or 110V.
Comprehensive battery protection: overvoltage, overtemperature, overload, overcharge, overdischarge, and short circuit protection with auto-recovery.
LED emergency lighting, 24V/12V cigarette lighter output, and 5V USB output.
Safe, reliable, and eco-friendly rechargeable lithium-ion battery.
Built-in LCD display.
High-power PD and QC protocol support via TYPE-C port.
PCBA Function Definition and Selection
AC/DC Input Charging – Define input power specifications, efficiency requirements, wide voltage range, and compliance with safety standards.
Battery Configuration – Determine battery capacity, series-parallel arrangement, lithium battery protection circuit, and whether balancing technology is required.
Display Options – Choose between LCD screen or digital tube display. Specify displayed parameters (power, voltage, battery capacity, remaining runtime) and required accuracy.
Inverter Output – Select inverter type: square wave, modified sine wave, or pure sine wave.
DC Output – Define required voltage/current groups, including PD/QC protocol TYPE-C port support and any custom voltage/current requirements.
Company Info
Shenzhen BQC Electronic Co, Itd, established in Shenzhen from 2003 in EMS(electronic manufacturing service) industry and dedicated to provide professional manufacturing ,OEM ODM service for electronic product to our all over the world
customers for over 22 years.
Our factory is 12000 m2 and about 600 people . There are 26 SMT production lines.6 DIP production line,3 hand soldering lines,3 final assembly line. And we can provide a full range of service, from PCBA to full turmkey box building.
We will take part in HK Electronics Fair and CES and Munich Electronics Fair every time.
Product Application
Medical Board PCB Assembly(ISO13485 PCBA)
Industrial Board PCB Assembly
Smart-home Board PCB Assembly
Consumer Board PCB Assembly
Telecommunication Board PCB Assembly
Automotive Board PCB Assembly(IATF16949 PCBA)
Security Board PCB Assembly
Company knowledge
Advantages of coating machine coating over traditional coating
Traditional coating:
1) Brush stroke: too slow, precision can not be controlled;
2) Spray gun spray: need clamp protection, too much spill;
2) Brush coating: there are bubbles, waves, and brush to remove hair;
4) The whole piece is soaked: too wasteful of paint and slow;
Coating machine coating:
1) The spray paint volume, spray paint position and area are set accurately, and there is no need to add someone to wipe the board after spraying;
2) Part of the plug-in components with a large distance from the edge of the board can be painted directly without mounting fixtures, saving board assembly personnel;
3) No gas volatilizes, ensuring a clean working environment;
4) All substrates do not need to use fixtures to cover the carbon film, eliminating the possibility of bumps;
5) The coating thickness of the conformal coating is uniform, which greatly improves the production efficiency and product quality, and at the same time avoids the waste of paint;
PCBA automatic conformal coating machine is an intelligent spraying equipment specially designed for spraying conformal coating. Due to the difference between the materials to be sprayed and the spraying liquids applied, the selection of parts of the coating machine in terms of the structure of the equipment is also different. The conformal coating machine adopts the latest computer control program, which can realize three-axis linkage, and is equipped with The camera positioning and tracking system can precisely control the spraying area.
FAQ
1. Q: Can you provide software design for ODM services?
A: Yes, we offer both software and firmware design services.
2. Q: What is your lead time for PCBAs?
Samples: 4 weeks
Mass production:
Material procurement: Typically 8 weeks (we can stock materials for customers if lead time exceeds 8 weeks)
Production: 4 weeks
Note on Material Stocking:
Most materials can be stocked free of charge.
If materials are customized and exclusive to your company (not usable by other customers), a deposit may be required.
